    Standard samples, tubes, etc.

    Add Bookmark

    Last update: 5 June 2024

    Standard sample
    Name P/N Qty Remarks Applicable models
    Standard sample for autotuning
    225-34260-01
    		400mL Nal (sodium iodide) 9030
    Standard sample for autotuning
    225-14124-01
    		200mL PEG (polyethylene glycol), raffinose 8080
    Standard sample for autotuning
    225-14122-01
    		200mL PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose 8060
    8050
    8030
    8040
    Standard sample for autotuning
    225-14985-01
    		200mL PEG (polyethylene glycol), PPG (polypropylene glycol), raffinose 2020
    Standard sample for autotuning
    225-06613-06
    		200mL PEG (polyethylene glycol), raffinose 2010
    Drain tube, nebulizer gas tube
    Name P/N Qty Remarks Applicable models
    Silicone rubber tube for waste liquid
    016-31350-19
    		1m For waste liquid from the waste tray 8060
    8050
    8030
    8040
    2020
    2010
    PVC tube for waste liquid
    016-31414
    		1m For waste liquid from the spray section 9030
    8060
    8050
    8030
    8040
    2020
    2010
    Rotary pump oil
    Name P/N Qty Remarks Applicable models
    Rotary pump oil  LV0700
    225-27850-02
    		1L 2 L per use 9030
    8060
    Rotary pump oil  Ultragrade#19
    017-30163-02
    		4L 1.5 L per use except 8080
    except 8060
    Rotary pump oil  GS495
    017-30168-01
    		1L 8080
    Sample delivery unit (for LCMS-8080)
    Name P/N Qty Remarks Applicable models
    Syringe for autotuning
    225-25043-41
    		5mL Inner diameter: 10.30 mm LCMS-8080
    PTFE tube
    228-18495-01
    		1m Cut the tube into 20 to 30 mm length pieces before use. LCMS-8080
    PEEK nut
    228-18565-84
    		5 LCMS-8080
    PEEK coupling
    228-25014
    		1 LCMS-8080
    Tee joint
    225-25031-10
    		1 LCMS-8080
    PEEK tube
    228-33833-91
    		3m Inner diameter: 0.13 mm LCMS-8080
    Straight joint
    225-25031-07
    		1 LCMS-8080
    Tube cutter
    225-25031-08
    		1 LCMS-8080
    Syringe for infusion analysis
    225-25031-02
    		1mL Inner diameter: 4.61 mm LCMS-8080
    Standard sample introduction unit (for LCMS-2010)
    Name P/N Appearance Qty Remarks Applicable models
    Plunger assembly
    228-25237-17
    		1 5mL LCMS-2010
    Reflex fitting set
    228-45407-92
    		Set of 5 Used for pipe connection from the 6-port valve to the ESI/APCI probe LCMS-2010
    Microsyringe1005C
    228-25237-07
    		228-25237-07 1 LCMS-2010
